Hikvision Audio Processor 8 Analog Input, 8 Analog Output (DS-QAPPR0808-D)

The DS-QAPPR0808-D combines multiple conventional audio-processing functions into a single professional digital processor. Its 32-bit floating-point DSP and 24-bit/48kHz conversion provide precise processing for conference rooms, meeting spaces, auditoriums, live sound and commercial AV systems.

The processor provides 8 balanced line-level inputs and 8 balanced line-level outputs, with a comprehensive processing chain including preamplification, parametric and graphic EQ, compression, automatic gain control, automatic mixing, ducking, feedback cancellation, acoustic echo cancellation and adaptive noise suppression.

A matrix mixing engine and support for up to 100 scene presets allow different room configurations or operating modes to be stored and recalled. Control is available through the supplied graphical software, while Ethernet, RS232, RS485 and 8 programmable GPIO interfaces provide integration with external control systems.

Key Features

• Professional 8 × 8 digital audio processor
• 8 balanced analogue inputs
• 8 balanced analogue outputs
• 32-bit floating-point DSP
• 24-bit / 48kHz A/D and D/A conversion
• Matrix mixing
• Acoustic Feedback Cancellation (AFC)
• Acoustic Echo Cancellation (AEC)
• Adaptive Noise Suppression (ANS)
• Ambient Noise Compensation (ANC)
• Automatic Gain Control (AGC)
• Automatic Mixer (AM)
• Compressor and expander
• Parametric and graphic EQ
• Crossover and limiter
• Up to 100 scene presets
• USB audio recording and playback
• Ethernet control
• RS232 and RS485 control
• 8 programmable GPIO interfaces
• 1.3-inch OLED display
• Windows, macOS, Linux, Android and iOS compatibility
