Hikvision Eco Series G3 86'' Android 14, EDLA (DS-D5A86RB/A3)
£1,982.40
£1,652.00
The Hikvision Eco Series DS-D5A86RB/A3 86" 4K WonderHub Class Interactive Display combines a large UHD touchscreen with Android 14 EDLA, upgradeability to Android 16, 8GB RAM and 128GB storage. Featuring 50-point infrared touch, 3 HDMI inputs, Wi-Fi 6, Bluetooth 5.4 and industrial-grade screen protection, it is ideal for classrooms, training rooms, meetings and collaborative environments.
IN STOCK
SKU
DS-D5A86RB-A3
Planning a larger AV project?
Discover our dedicated Pro division for expert design, installation, and commercial solutions.
Simply AVS are able to offer significant discounts for Education customers, and for larger orders. Purchase orders welcome. Finance options available. Contact us today
Hikvision DS-D5A86RB/A3 86" 4K Interactive Display
The Hikvision DS-D5A86RB/A3 is an 86-inch 4K UHD interactive touchscreen designed for modern education, business, training and collaborative environments. It delivers a large, highly detailed display with responsive infrared touch technology and an integrated Android platform.
86" 4K UHD Display
The 86-inch DLED display provides 3840 × 2160 4K UHD resolution at 60Hz, with 400 cd/m² brightness, 10-bit colour depth and 1.07 billion display colours. The IPS panel provides 178° horizontal and vertical viewing angles, while anti-glare glass and 9H surface hardness provide protection for intensive classroom and commercial use.
50-Point Interactive Touch
The integrated infrared touchscreen supports up to 50 simultaneous touch points, with ≤5ms touch response and ±0.5mm precision across at least 90% of the touch area. This makes the display suitable for collaborative annotation, interactive teaching, presentations and group work.
Android 14 EDLA / Android 16 Upgradeable
The original DS-D5A86RB/A3 specification features Android 14.0, 8GB memory and 128GB built-in storage. Hikvision's current product page now lists the model with Android 16.0 and EDLA certification, making Android 14 with Android 16 upgradeability an appropriate description for the original stock configuration.
Connectivity
The display provides 3 × HDMI 2.1 inputs, USB 3.0, USB 2.0, USB Type-C, dual Gigabit LAN, Wi-Fi 6, Bluetooth 5.4 and NFC. Integrated 2 × 20W speakers provide built-in audio for lessons, meetings and presentations.
Key Features
- 86" 4K UHD interactive display
- 3840 × 2160 resolution @ 60Hz
- Android 14 EDLA
- Upgradeable to Android 16
- 8GB RAM + 128GB storage
- Up to 50-point infrared multi-touch
- 400 cd/m² brightness
- IPS panel
- 5ms display response time
- ≤5ms touch response
- 9H pencil / 7 Mohs surface hardness
- Anti-glare glass
- 25% haze
- Zero-lamination glass bonding
- 3 × HDMI 2.1 inputs
- Bluetooth 5.4
- Wi-Fi 6
- NFC support
- Built-in 2 × 20W speakers
- USB Type-C with 15W charging
- VESA 800 × 600mm
- Wall mount bracket included
- 50,000-hour lifespan
- Designed for education, business, training and collaboration
Display
| Specification | Details |
|---|---|
| Screen Size | 86 inch |
| Backlight | DLED |
| Panel Type | IPS |
| Resolution | 3840 × 2160 @ 60Hz |
| Aspect Ratio | 16:9 |
| Pixel Pitch | 0.164 (H) × 0.493 (V) mm |
| Brightness | 400 cd/m² |
| Colour Depth | 10-bit (8-bit + FRC) |
| Display Colours | 1.07 billion |
| Response Time | 5ms |
| Static Contrast | 1200:1 |
| Dynamic Contrast | 15,000:1 |
| Colour Gamut | 72% NTSC |
| Viewing Angle | 178° H / 178° V |
| Refresh Rate | 60Hz |
| Surface Hardness | 9H Pencil / 7 Mohs |
| Glass | Anti-glare |
| Surface Haze | 25% |
| Glass Bonding | Zero Lamination |
| Display Area | 1895.04 × 1065.96mm |
| Transmittance | 88% ±3 |
| Lifespan | 50,000 hours |
| Working Duration | 7 × 16 hours |
Touch
| Specification | Details |
|---|---|
| Technology | Infrared Touch Screen |
| Touch Points | Up to 50-point multi-touch |
| Touch Response | ≤5ms |
| Minimum Touch Object | ≥1.5mm |
| Touch Precision | ±0.5mm |
| Touch Resolution | 32768 × 32768 |
Built-in System
| Specification | Details |
|---|---|
| Operating System | Android 14.0 / Android 16 current firmware |
| RAM | 8GB |
| Storage | 128GB |
| Processor | Quad Cortex-A72 ×4 @ 2.2GHz + Quad Cortex-A53 ×4 @ 1.8GHz |
| GPU | Mali-G52 MC3 |
| HDCP | 2.3 / 2.0 / 1.4 |
| EDLA | Certified |
Audio & Wireless
| Specification | Details |
|---|---|
| Speakers | 2 × 20W |
| Bluetooth | Bluetooth 5.4 |
| Wi-Fi | Wi-Fi 6 |
| Wi-Fi Bands | 2.4GHz / 5GHz |
| MIMO | 2 × 2 |
| NFC | 13.56MHz, ISO 14443A / ISO 14443B |
| Light Sensor | Yes |
Connectivity
| Interface | Quantity / Details |
|---|---|
| HDMI | 3 × HDMI 2.1 — 1 front, 2 rear |
| Audio Input | 1 × rear |
| Audio Output | 1 × rear |
| TOUCH-USB | 2 × USB 2.0 |
| RS232 | 1 × rear |
| LAN | 2 × Gigabit / 1000Mbps |
| USB 3.0 | 2 × front |
| USB 2.0 | 2 × rear |
| USB Type-C | 1 × front, USB 3.0 + 15W charging |
| TF Card | 1 × rear |
Power & Physical Specifications
| Specification | Details |
|---|---|
| Power Supply | 100–240VAC, 50/60Hz |
| Average Consumption | <210W |
| Standby Consumption | ≤0.5W |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 10–90% RH |
| VESA Mount | 800 × 600mm, 4 × M8-25mm |
| Dimensions Without Wall Attachment | 1957.04 × 1156.5 × 95.8mm |
| Dimensions With Wall Attachment | 1957.04 × 1156.5 × 123.0mm |
| Net Weight | 52.38 ±0.5kg |
| Gross Weight | 69.89 ±0.5kg |
| Package Dimensions | 2157 × 1345 × 223mm |
| ean | 6942640549874 |
|---|---|
| Brand | Hikvision |
| Education discount | EDUCATION DISCOUNTS |
| Google EDLA | No |
| Screen Size | 86" |
| Android Version | 16 |
| Resolution | 4K UHD (3840 x 2160) |
| Brightness | 400 nits |
