Hikvision Pro Amplifier 500w, 4-channel (DS-QAPAR50-4)
£612.00
£510.00
The Hikvision DS-QAPAR50-4 is a professional 4-channel Class D power amplifier delivering 4 × 500W at 8Ω. It supports 2–8Ω loads, stereo, bridge and connect modes, independent channel control and selectable gain from 26–41dB. Its compact 1U chassis and high-efficiency switching power supply make it suitable for professional sound reinforcement and commercial audio installations.
IN STOCK
SKU
DS-QAPAR50-4
Planning a larger AV project?
Discover our dedicated Pro division for expert design, installation, and commercial solutions.
Simply AVS are able to offer significant discounts for Education customers, and for larger orders. Purchase orders welcome. Finance options available. Contact us today
The DS-QAPAR50-4 is designed for demanding professional audio applications where four independently controlled amplifier channels are required. It delivers 4 × 500W into 8Ω, increasing to 4 × 765W at 4Ω and 4 × 1301W at 2Ω in stereo mode. Bridge operation provides up to 2 × 2,601W at 4Ω.
The Class D architecture provides power efficiency of up to 90%, while the PFC full-bridge switching power supply supports a wide 90–260VAC input range. Stereo, bridge and connect modes provide installation flexibility, while the selectable gain range and limiter switch allow the amplifier to be adapted to different professional audio systems.
The amplifier uses four XLR inputs and four SPEAKON outputs and occupies only 1U of 19-inch rack space. Comprehensive protection includes over-temperature, DC, short-circuit, signal overload, soft-start and power-supply over-current protection.
Key Features
- Professional 4-channel / 4-zone power amplifier
- Class D digital amplification
- 4 × 500W @ 8Ω
- 4 × 765W @ 4Ω
- 4 × 1,301W @ 2Ω
- Bridge: 2 × 900W @ 16Ω
- Bridge: 2 × 1,530W @ 8Ω
- Bridge: 2 × 2,601W @ 4Ω
- 2–8Ω load support
- Stereo, Bridge and Connect modes
- Selectable gain: 26–41dB
- Limiter switch
- Up to 90% power efficiency
- PFC full-bridge switching power supply
- 90–260VAC input
- 4 × XLR inputs
- 4 × SPEAKON outputs
- 1U, 19-inch rack format
- Independent channel control
- Variable-speed low-noise cooling fan
- Comprehensive protection circuitry
| Specification | DS-QAPAR50-4 |
|---|---|
| Product type | Professional power amplifier |
| Amplifier class | Class D |
| Channels / zones | 4 |
| Rated power @ 8Ω stereo | 4 × 500W |
| Rated power @ 4Ω stereo | 4 × 765W |
| Rated power @ 2Ω stereo | 4 × 1,301W |
| Bridge @ 16Ω | 2 × 900W |
| Bridge @ 8Ω | 2 × 1,530W |
| Bridge @ 4Ω | 2 × 2,601W |
| Load impedance | 2–8Ω |
| Frequency response | +0 / -0.5dB, 20Hz–20kHz |
| THD | 0.01% |
| SNR | ≥105dB, A-weighted |
| Input impedance | 20kΩ balanced / 10kΩ unbalanced |
| Maximum input level | 14V |
| Gain | 26–41dB |
| Inputs | 4 × XLR |
| Outputs | 4 × SPEAKON |
| Operating modes | Stereo / Bridge / Connect |
| Limiter | Supported |
| Power efficiency | Up to 90% |
| Power supply | 90–260VAC, 50/60Hz |
| Rack format | 1U |
| Dimensions | 483 × 44 × 370mm |
| Net weight | Approx. 9kg |
| Cooling | Variable-speed fan |
| Installation | 19-inch rack |
| Brand | Hikvision |
|---|---|
| Google EDLA | No |
