Hikvision Eco Series G3 75'' Android 14, EDLA (DS-D5A75RB/A3)
£1,390.80
£1,159.00
The Hikvision Eco Series DS-D5A75RB/A3 75" WonderHub Class Interactive Display delivers 4K UHD resolution, 50-point infrared touch and Android 14 EDLA, with upgradeability to Android 16. Featuring 8GB RAM, 128GB storage, 3 HDMI inputs, Bluetooth 5.4 and durable industrial-grade screen protection, it is ideal for classrooms, training rooms, meetings and collaborative environments.
IN STOCK
SKU
DS-D5A75RB-A3
Planning a larger AV project?
Discover our dedicated Pro division for expert design, installation, and commercial solutions.
Simply AVS are able to offer significant discounts for Education customers, and for larger orders. Purchase orders welcome. Finance options available. Contact us today
Hikvision DS-D5A75RB/A3 75" 4K Interactive Display
The Hikvision DS-D5A75RB/A3 is a 75-inch 4K interactive touchscreen designed for modern classrooms, meeting rooms, training environments and collaborative spaces. Part of the WonderHub/Value G3 range, it combines a high-quality UHD display with responsive infrared touch technology and an integrated Android platform.
4K UHD Interactive Display
The 75-inch display provides a 3840 × 2160 4K UHD resolution at 60Hz, with 400 cd/m² brightness, 1.07 billion colours and a 5ms response time. The IPS panel offers wide 178° viewing angles, while anti-glare glass and 9H surface hardness help provide comfortable and durable everyday use.
Android 14 EDLA with Android 16 Upgradeability
The DS-D5A75RB/A3 features Android 14 with EDLA certification, 8GB of RAM and 128GB of built-in storage. Hikvision's current product information also lists Android 16 for this model following the platform upgrade.
50-Point Infrared Touch
Up to 50 simultaneous touch points provide smooth, responsive interaction for writing, annotation, presentations and collaborative work. Touch response is up to 5ms with ±0.5mm touch precision across at least 90% of the touch area.
Connectivity
The display includes 3 HDMI inputs, USB connectivity, USB Type-C, dual LAN, Wi-Fi 6, Bluetooth 5.4 and NFC support. Built-in 2 × 20W speakers provide integrated audio for presentations, lessons and video content.
Key Features
- 75-inch 4K UHD interactive display
- 3840 × 2160 resolution at 60Hz
- Android 14 EDLA
- Upgradeable/currently supported with Android 16
- 8GB RAM + 128GB storage
- Up to 50-point infrared multi-touch
- 400 cd/m² brightness
- IPS panel
- 9H tempered/industrial-grade screen protection
- Anti-glare glass
- 3 × HDMI inputs
- Bluetooth 5.4
- Wi-Fi 6
- NFC support
- Built-in 2 × 20W speakers
- VESA 600 × 400 mounting
- Wall mount bracket included
- Designed for education, business, training and collaboration
Technical Specifications
| Specification | DS-D5A75RB/A3 |
|---|---|
| Screen Size | 75 inch |
| Backlight | DLED |
| Panel Type | IPS |
| Resolution | 3840 × 2160 @ 60Hz |
| Aspect Ratio | 16:9 |
| Pixel Pitch | 0.143 (H) × 0.429 (V) mm |
| Brightness | 400 cd/m² |
| Colour Depth | 10-bit (8-bit + FRC) |
| Display Colours | 1.07 billion |
| Response Time | 5ms |
| Static Contrast Ratio | 1200:1 |
| Dynamic Contrast Ratio | 15,000:1 |
| Colour Gamut | 72% NTSC |
| Viewing Angle | 178° H / 178° V |
| Surface Hardness | 9H Pencil / 7 Mohs |
| Surface Glass | Anti-glare glass |
| Surface Haze | 25% |
| Glass Bonding | Zero Lamination |
| Active Display Area | 1650.24 × 928.26 mm |
| Transmittance | 88% ± 3 |
| Lifespan | 50,000 hours |
| Working Duration | 7 × 16 hours |
Touch Specifications
| Specification | Details |
|---|---|
| Touch Technology | Infrared |
| Touch Points | Up to 50-point multi-touch |
| Touch Response | ≤5ms |
| Minimum Touch Object | ≥1.5mm |
| Touch Precision | ±0.5mm |
| Touch Resolution | 32768 × 32768 |
Built-in System
| Specification | Details |
|---|---|
| Operating System | Android 14 EDLA / Android 16 current firmware |
| RAM | 8GB |
| Storage | 128GB |
| CPU | Quad Cortex-A72 ×4 @ 2.2GHz + Quad Cortex-A53 ×4 @ 1.8GHz |
| GPU | Mali-G52 MC3 |
| HDCP | 2.3 / 2.0 / 1.4 |
Audio & Wireless
| Specification | Details |
|---|---|
| Speakers | 2 × 20W |
| Bluetooth | Bluetooth 5.4 |
| Wi-Fi | Wi-Fi 6, 2.4GHz / 5GHz |
| Wi-Fi Configuration | 2 × 2 MIMO |
| NFC | 13.56MHz, ISO 14443A / ISO 14443B |
| Light Sensor | Yes |
Connectivity
| Interface | Quantity / Details |
|---|---|
| HDMI | 3 × HDMI 2.1 TMDS — 1 front, 2 rear |
| Audio Input | 1 × rear |
| Audio Output | 1 × rear |
| TOUCH-USB | 2 × USB 2.0 |
| RS232 | 1 × rear |
| LAN | 2 × Gigabit / 1000Mbps |
| USB 3.0 | 2 × front |
| USB 2.0 | 2 × rear |
| USB Type-C | 1 × front, USB 3.0 + 15W charging |
| TF / microSD | 1 × rear |
Power & Physical Specifications
| Specification | Details |
|---|---|
| Power Supply | 100–240VAC, 50/60Hz |
| Average Consumption | <189W |
| Standby Consumption | ≤0.5W |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 10–90% RH |
| VESA Mount | 600 × 400mm, 4 × M8-25mm |
| Dimensions Without Wall Attachment | 1709.84 × 1017.34 × 95.75mm |
| Dimensions With Wall Attachment | 1709.84 × 1017.34 × 124.45mm |
| Net Weight | 41.23 ± 0.5kg |
| Gross Weight | 54.3 ± 0.5kg |
| Package Dimensions | 1907 × 1160 × 223mm |
What's Included
- Wall mount bracket
- Hook
- Touch writing pen
- Power cable
- Remote control
- User manual
- Packing list
| ean | 6942640549898 |
|---|---|
| Brand | Hikvision |
| Google EDLA | No |
| Screen Size | 75" |
| Android Version | 16 |
| Resolution | 4K UHD (3840 x 2160) |
| Brightness | 400 nits |
